New VERICUT® CNC Machine Connectivity Feature Improves Program Accuracy Through Digital Twin Technology

Latest feature to be displayed at the Shop Floor Automations booth at IMTS 2024 in Chicago

Shop Floor Automations (SFA), a manufacturing integrator specializing in digitally transformative hardware, software and support solutions, will demonstrate the new Postcheck feature of the VERICUT® CNC Machine Connectivity software at IMTS 2024 from September 9-14 in Chicago, Illinois. This feature of CNC Machine Connectivity, which utilizes the Scytec DataXchange machine monitoring solution, supports the analysis of digital twin simulations through the replay of stored, live-streamed data from the numerical control (NC) machine. Through such replays, Postcheck allows programmers to retrieve archived data from when a part was machined, then rerun that data in VERICUT® to investigate issues that may have occurred during the machining process.

The VERICUT® CNC Machine Connectivity modules were launched as an add-on to the 9.3 release of VERICUT® software in 2022 through a partnership between CGTech and Scytec Consulting Inc. CNC Machine Connectivity aligns digital twin simulations of CNC programs and live production to enable manufacturers to detect, communicate and validate variances in order to produce higher quality parts at faster rates.

“After verifying NC programs and sending them to the shop floor, NC programmers frequently lose visibility into what happened with those programs in the shop. When asking the machine operator or shop foreman about the performance of the NC programs and any necessary changes, their responses can be too vague at times to identify how or where modifications were needed. This means the same issues will likely occur the next time the programs run,” says CGTech director of product management, Gene Granata. “The Postcheck feature of CNC Machine Connectivity closes the loop on the NC programming process by providing engineers and programmers with access to factually-recorded data about how NC machines and programs ran, including exact spindle or feed rate override percentages or emergency stops that occurred, right at their fingertips.”

VERICUT CNC Machine Connectivity Postcheck

The new Postcheck feature of VERICUT® CNC Machine Connectivity software allows programmers to document and verify actual jobs at any time and location to increase productivity and program accuracy.

As a reseller of DataXchange and various CNC hardware and software solutions, SFA president Greg Mercurio understands the opportunity CNC Machine Connectivity offers those involved with NC manufacturing.

“This latest feature of CNC Machine Connectivity is yet another example of how today’s technology is tightening the processes and relationship between engineering, programming, quality, estimating and the machine shop and tool crib on the floor,” states Mercurio. “We’re excited to share the range of possibilities with manufacturers at this year’s IMTS.”

For more information about DataXchange machine monitoring or the VERICUT® CNC Machine Connectivity software, visit the SFA booth (#133240) at IMTS 2024, call SFA at 619-461-4000 or visit www.shopfloorautomations.com.

IMTS 2024 attendees can visit Shop Floor Automations for manufacturing integration solutions and support
, , , ,

Map Your Show with this IMTS 2024 Exhibitor Lineup

“Everything we have today is the result of going to Chicago, walking through those doors of IMTS, and seeing all the amazing technology. It’s a great atmosphere. It’s like walking into a living room that’s set up as a CNC shop with people smiling and ready to help you.”

 — Ashley Miller, Co-owner, ARC EDM

For those who attended the International Manufacturing Technology Show (IMTS) 2022, like Miller, they know that there was plenty to keep over 86,000 registrants from 110 countries interested in the 1,816 exhibitors. IMTS 2024 promises much more, with many new product launches and networking connections anticipated over the course of the six-day event.

Visit Shop Floor Automations at IMTS 2024 in Chicago

New Products, New Connections

ZOLLER (booth #432018), for one, plans to introduce its >>coraMeasure LG<< automated tool measurement system to improve tool measurement precision and speed by delivering tools to a linear robot that removes tools from the pallet and moves them to a ZOLLER >>venturion<< presetting and measuring machine. Each tool is identified with the ZOLLER >>dChip<< system and tool data is stored in the ZOLLER z.One database and accessible anywhere.

The new HAIMER (Booth #431510) Automation Cube One will also make its debut at IMTS 2024. This fully automatic robotic cell can shrink fit a tool, measure it and send the data to the machine tool in just 60 seconds. The Automation Cube One features a FANUC cobot for handling of tool assemblies and a Siemens Sinumerik One CNC control.

IMTS machine monitoring exhibitor Shop Floor Automations

DataXchange, available through IMTS machinoe monitoring exhibitor Shop Floor Automations, has released new protocol for supported equipment brands, including Okuma, Heidenhain and Siemens.

For those exploring machine monitoring and data collection solutions, Scytec Consulting (Booth #133240) has released new protocol for machine brands like Okuma, Heidenhain and Siemens to connect more data points for greater depth and analysis of equipment on the shop floor with its DataXchange equipment monitoring software. The added collection of Siemens spindle speed rates, for example, can help identify faults for better finish and surface quality due to consistent cutting speed at the tool cutting edge.

The partnership between Scytec and CGTech’s VERICUT® takes machine monitoring a step further through digital twins to simulate your manufacturing environment and identify the presence of variances before production begins on the floor, thereby minimizing or eliminating non-conformances and rework. Attendees seeking an IMTS machine monitoring exhibitor will have first access to the latest Post Check feature of CNC Machine Connect, in which users may replay stored, live-streamed data from the program for even greater visibility and predictive accuracy of your simulations.

IMTS 2024 attendees can visit Shop Floor Automations for manufacturing integration solutions and support

Greg Mercurio, president of manufacturing integrator Shop Floor Automations, says that “It’s the relationships that we start and build at IMTS that make the show such a vital experience. Not only are we able to demonstrate the latest advances in our technology portfolio, but our deep customer connections allow us to match the right solution and service to their environment so they can focus on their producing high-quality product.”

To plan your IMTS show with these exhibitors and others, visit www.imts.com.

AWS GovCloud-secure DataXchange machine monitoring for CNC and other manufacturing equipment
, , ,

AWS GovCloud-secure Machine Monitoring Featured at North America’s Largest Metal Forming, Fabricating, Welding and Finishing Event

Manufacturing integrator Shop Floor Automations (SFA) will showcase the AWS GovCloud-secure Scytec DataXchange machine monitoring solution for highly-regulated industries, including aerospace, defense and pharmaceutical, at FABTECH 2023. FABTECH is North America’s largest metal forming, fabricating, welding and finishing event and will be held September 11-14 at McCormick Place in Chicago, IL.

For manufacturers adhering to regulations like International Traffic in Arms (ITAR), Defense Federal Acquisition Regulation Supplement (DFARS) and other security and compliance requirements, the ability to monitor disparate machines, each with a unique control system and communication protocol with varying ages, can make continuous improvement initiatives challenging in the cloud. There is often limited capability to protect and restrict access to sensitive data, such as Controlled Unclassified Information (CUI) and Personally Identifiable Information (PII), while also granting the visibility needed to make timely, data-driven decisions that can impact every aspect of a manufacturer.

The DataXchange solution, available through SFA, resolves these issues by leveraging AWS GovCloud to capture real-time, Industrial Internet of Things (IIoT) data from a variety of equipment – from lasers and press brakes, to saws and robots – through universal machine connections. Leveraging automated data collection, DataXchange exposes and synthesizes equipment data to give teams full transparency on the shop floor through an architected secure cloud solution for a total smart factory transformation.

DataXchange leverages AWS GovCloud to monitor machine data in aerospace, defense and pharmaceutical manufacturing environments.

DataXchange leverages AWS GovCloud to capture real-time IIoT data from a variety of equipment – from lasers and press brakes, to saws and robots – through universal machine connections.

Results include a 62.5% decrease in machine time as a result of time-saving alerts, reported user MOGAS. The severe service ball valve manufacturer anticipates a full Return on Investment (ROI) within a year of implementing DataXchange.

Manufacturers are invited to stop by the SFA Booth, A3255, at FABTECH 2023 for a complimentary demonstration of the secure DataXchange solution and to explore the entire SFA product portfolio to help resolve the challenges of the modern shop floor.

For sales inquiries, call 619-461-4000 or visit www.shopfloorautomations.com.



ABOUT Shop Floor Automations

Founded in 1998, Shop Floor Automations (SFA) is a manufacturing integrator specializing in digitally transformative hardware, software and support solutions to increase the productivity, efficiency and profitability of plant facilities throughout North America. To add intelligent automation to your shop floor for better communication, control and improvement, contact Shop Floor Automations at www.shopfloorautomations.com.
