DNC Networking Software for CNC Communication to Machines

DNC software for CNC communication


Shop Floor Automations has been providing DNC software to communicate to CNC machines since 1998. We provide two leading software product lines: Predator Software and Ascendant Technologies.

Most companies have methods to deliver files to machines, but are limited to using floppy disks, USB sticks, PCMCIA cards, and tape readers—or even manual typing. Theses methods use several hours to load programs, but offer no revision control, management of proven or released files, or traceability.

With our solutions, we can implement a product that improves productivity and tracks every upload, download or drip-feed to the CNC, while decreasing the time it takes to load programs. Every minute on the shop floor counts, and if we can save you 5 minutes a day, your new system could be paid for in months.

We offer wired and wireless solutions, personalized to meet your specific needs. Want to learn more? Visit us at shopfloorautomations.com or call us at 877-611-5825. More info on our DNC Solutions:

Manage your CNC programs, machine parameters, & offsets. Enjoy a wide range of CNC communication options from your Predator PCs for drip-feeding, downloading, & bi-directional communication. Upload via parallel, RS232, RS422 Ethernet, & wireless Ethernet for thousands of CNC machines. With Microsoft Office  & Windows Explorer-compatible user interface (Windows 10 O/S supported), use familiar features for drag & drop, cut, copy, paste, shortcut menus, object-based menus, toolbars, tool tips, & available online help.

Improve CNC revision control while using existing ERP & MES bar-coded paperwork. Eliminate time wasted walking back & forth between your CNC & PC with a Remote Request function. Consider a 32-Bit, Multi-thread, Multi-tasking, Open-Architecture DNC Software solution that works wired & wirelessly.

Simplify operations with one network for all of your CNC machines, Robots, PLCs, & part makers, grouped by building or cell.

We offer the following DNC Communication solutions: Predator DNC, Ascendant extremeDNC, Predator TouchHMI, and Predator EditLock. We also have many pieces of hardware to help your shop floor achieve wireless DNC.

Automate your CNC with DNC software

Automate CNC machines with DNC software

View this brief video for more information on how we can help automate your CNC machine.

Via our Software solutions page:

Shop Floor Automations (SFA) uses the top software brands in the manufacturing industry to provide and support the best solutions for our customers. They can make your machine shop more efficient using machine monitoring, job scheduling, DNC, document control, CNC editing, and more.

SFA is committed to addressing manufacturing automation needs of customers with individualized solutions. By offering an extensive collection of software and hardware products, they scale automation solutions to customers of any size and range. SFA’s goal is to build lasting partnerships with customers by understanding their specific manufacturing & production needs.

Ascendant Technologies – Manufacturing industry software applications

  • eXtremeDNC: Drip-feeding & bi-directional communication with over 1000 CNCs.
  • XYZPRO 32 Plus: User friendly G-Code editing & backplotting.

Predator Software – Automate, network, monitor & control your machine shop

  • CNC Editor: Shop floor editing, tracking & control.
  • DNC: Shop floor connectivity, controls & communication.
  • MDC:  Data collection of shop floor productivity metrics to improve operations & decisions.
  • PDM: SFA helps coordinate & control shop documents plus revisions.
  • Tracker: Help for shop floor editing, tracking & control.

Scytec – Data collection to get the most of your machines

  • DataXchange: Tools to measure, analyze & improve your shop floor.

MTConnect – SFA utilizes this universal factory floor communication standard to enable the efficient transfer of data between devices & software applications. More info here

Call (877) 611-5825 for more information



SFA in February 2014 Manufacturing News

February 2014 Manufacturing News

Read our article about DNC in this month’s Manufacturing News issue, “SFA + Predator DNC Software For Windows”

Shop Floor Automations NewsletterShop Floor Automations (SFA), a provider of software for the manufacturing shop floor, installed Predator’s version 9.0.16 through the end of 2013 while beta testing version 10.0 of Predator DNC Software and Editor.

Version 9.0 has been installed at hundreds of different sites. The main benefit is its compatibility with Windows 7 and Windows 2008/2012 server, including both 32- and 64-bit Operating systems.

“The DNC is easily migrated from previous versions running under Windows XP to the latest Predator DNC with our migration tools and hardware program,” said SFA President Greg Mercurio. “Customers have used the same solution for years from us and if it works, they do not want to change anything unless needed. Because of the end to Microsoft’s support for Windows XP, we have created a program to assist customers in keeping their machines up and running without interrupting production.”

SFA can provide end users with new hardware to integrate their existing wired system into wireless 802.11 B/G or embrace Ethernet technology on the shop floor. The use of RS232 serial ports is being phased out and networking CNC machines is becoming more prevalent. Predator Software includes functionality to communicate via FTP or Windows Share, and supports the use of the FANUC FOCAS to simplify file transfers. RS232 standard protocol is also included to support the hundreds of legacy CNC controllers with enhanced file management tools to automate the download and upload process.

Read the whole piece here! You may also call SFA and ask us about more Predator Software solutions at (877) 611-5825.

The different Predator solutions we are offer: DNC. Touch HMI, EditLock, MDC, CNC Editor, CNC Editor Express, CNC Editor Light, PDM, and Tracker. We have been the number one reseller of Predator Software since 1999 and continue to customize this solution to fit customer needs. Ask about demos and free trials!



Predator DNC Version 9.0 Released

Predator DNC SoftwarePredator DNC Software Version 9.0

With the new operating system released by Microsoft, Predator has responded and released Predator DNC Version 9.0 through the Predator MES Suite v9.0. Shop Floor Automations (SFA), the largest distributor and service center for Predator Software today announced implementing the new release and training on the product.

Whether using a wireless or wired network, RS232 or Ethernet, DNC can be configured to remotely upload, download and drip-feed from a single CNC Control Panel to as many as 256 CNCs, whether they are across the shop floor or across the globe. And now Predator DNC is even better with version 9.0.

In addition to Windows Vista, version 9.0 also supports Microsofts other 64-bit systems XP Professional x64 Edition, and Windows 2003 Server x64 – along with Microsoft Excel 2007, Access 2007 and Oracle Database 11g.

Predator DNC v9.0 also offers new Fanuc Focus connection to machines for transferring NC programs via Ethernet for uploading, downloading and drip-feeding. Plus it comes with the newly released Predator CNC Editor v9.0, which contains dozens of new features, such as several new CNC programming wizards and all new backplotting with support for Predator Dynamic Graphics.

More about DNC Communications solutions through Shop Floor Automations:

Manage your CNC programs, machine parameters, & offsets. Enjoy a wide range of CNC communication options from your Predator PCs for drip-feeding, downloading, & bi-directional communication. Upload via parallel, RS232, RS422 Ethernet, & wireless Ethernet for thousands of CNC machines. With Microsoft Office  & Windows Explorer-compatible user interface (Windows 10 O/S supported), use familiar features for drag & drop, cut, copy, paste, shortcut menus, object-based menus, toolbars, tool tips, & available online help.

Improve CNC revision control while using existing ERP & MES bar-coded paperwork. Eliminate time wasted walking back & forth between your CNC & PC with a Remote Request function. Consider a 32-Bit, Multi-thread, Multi-tasking, Open-Architecture DNC Software solution that works wired & wirelessly.

Automate and Streamline Moldmaking with DNC Software

DNC SoftwareDNC Software  for Moldmaking Automation

Shop Floor Automations (La Mesa, CA), the leading reseller and support provider for Predator Software, offers the perfect solution to automate and streamline the moldmaking process.

Predator DNC Software is designed to allow moldmaking applications to communicate with up to 256 CNCs simultaneously from a single PC. Predator DNC works in the background, even while other applications are running, to drip-feed large programs typically used by mold makers. Predator also includes a Server Safe Mode to protect against lost data in the event of a network crash during drip feed transfers. The software also supports various baud rates up to 256,000bps to allow for fast through-put to the machine to eliminate starving the control, which is common when running at lower baud rates.

The most used feature in the software is the DNC restart functionality to allow for the operator to restart mid-tape should a tool break in the middle of the program. The user can also specify a string of text that is then inserted at the beginning of the CNC program that is sent.

Predator DNC comes standard with protocols for error-free communication to packetize the data as the NC programs are being requested from the CNC controller. These protocols include Bridgeport Easylink, Brother Dialog, Fagor, Heidenhain Blockwise, Okuma B, and Xmodem at no additional cost.

This article was featured in Mold Making Technology. Read it here.

Another Success Story

Stryker Reduces Errors with Predator Desktop

A Nice, Tidy Operation – Predator Software case study

Predator SoftwareNowadays, joint replacements are expected to meet greater demands and be in service longer than ever before. This means ever-increasing demand on design and production, ensuring maximum joint mobility; whilst minimizing wear, through the use of materials such as ceramics, titanium, and polyethylene.

Also, to meet the ever-widening range of issues, preferences, and patient demands, surgeons must have an equally wide range of choices and options so that the right joint is readily available whatever size the patient.

All this puts pressure on companies like Stryker Corporation, which specializes in manufacturing medical equipment. It has to deal with numerous design variations and batch changeovers daily, whilst maintaining traceability and effective production within the bounds of strict regulation.

Not easy by anyone’s standards; there are many opportunities for operator error, especially when changing one batch of components for another – which may look exactly the same, but embrace dimensional changes too small for most to see. Such errors prompted senior information technology analyst Walter Switzer of Stryker’s facility in Cork to seek a solution.

He found it in a bespoke DNC installation developed in conjunction with Predator Software Europe. The first two parts of the proposed three-part installation have been a huge success: the possibility of downloading the wrong file has been obliterated, and productivity significantly improved. In fact, the system now manages everything associated with making products on the machines and is currently being implemented across the American plants as a result. Read more below.

Read more
